XC400/600 - CONTROLLERS FOR APPLICATIONS UP TO 6 COMPRESSOR/FAN OUTPUT - XC642C
Generals
N° digits display 1 (suction): ± 3 d.p.
N° digits display 2 (condensing): ± 4 d.p.
Power supply: 12, 24Vac/dc
Probe inputs
Regulation: NTC/PTC/4÷20mA
Liquid injection: PTC
Digital inputs
Low pressure switch: present
High pressure switch: present
Alarm: 4
ON/OFF, liquid level: configurable
Relay outputs
Loads: 5x6A
Logger
Alarms: last 10
Other
Hot Key / Prog Tool Kit output: present
Serial output: TTL
Alarm output: 12V
Triac output: trigger optional
Fan output: 4÷20mA optional
Buzzer: optional
